Product Description
The Hikvision DS-2CD3356G2-ISU is a 5MP turret camera built for anyone who wants sharp daytime footage and usable night-time detail without fiddling with a varifocal lens.
What it actually gives you
- 5MP sensor (2592 × 1944) — enough detail to identify faces or number plates close to the lens, not just shapes.
- Fixed 2.8mm lens, 98° field of view — wide enough to cover a doorway, driveway or corridor in one shot; there's no zoom, so pick a mounting spot that already frames what you need.
- Infrared night vision to 40m, with Smart Supplement Light automatically balancing the beam so close-up subjects don't wash out white at night.
- 120 dB WDR helps in tricky spots like a doorway facing bright sky, keeping both the sky and the shadowed entrance visible.
- AcuSense analytics tell people and vehicles apart from cats, foxes and blowing leaves, cutting down pointless alerts — useful if you're the one checking notifications.
- Built-in microphone plus audio in/out — check whether you need a separate line-level input before assuming the built-in mic is enough for your setup.
Storage and power
Recordings can be kept locally on a microSD card up to 512GB, which matters if you're not running an NVR everywhere. It's powered over PoE (802.3af) or 12V DC, and the metal housing is IP67-rated, so it's built to stay outdoors year-round.
Specifications
- Brand
- Hikvision
- Image Sensor
- 1/2.7" Progressive Scan CMOS
- Max Resolution
- 2592 × 1944
- Min. Illumination
- Colour: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR
- Shutter Time
- 1/3 s to 1/100, 000 s
- Day & Night
- IR cut filter
- Lens Type
- Fixed focal lens, 2.8mm optional
- Lens Mount
- M12
- DORI
- 2.8 mm: D: 64 m, O: 25 m, R: 12 m, I: 6 m
- Supplement Light Type
- IR
- Supplement Light Range
- Up to 40 m
- Smart Supplement Light
- Yes
- IR Wavelength
- 850 nm
- Video Bit Rate
- 32 Kbps to 16 Mbps
- Environment Noise Filtering
- Yes
- User/Host
- Up to 32 users. 3 user levels: administrator, operator and user
- Security
- Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Network Storage
- MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- Client
- iVMS-4200, Hik-Connect, Hik-Central
- Image Parameters Switch
- Yes
- Image Settings
- Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Day/Night Switch
- Day, Night, Auto, Schedule
- Wide Dynamic Range (WDR)
- 120 dB
- SNR
- ≥ 52 dB
- Ethernet Interface
- 1 RJ45 10 M/100 M self-adaptive Ethernet port
Technical Specifications
Frequently Asked Questions
How far does the night vision reach?
The infrared range is up to 40 metres, with Smart Supplement Light adjusting intensity so nearby subjects don't overexpose.
Can I record without an NVR?
Yes — it supports onboard microSD storage up to 512GB, in addition to recording via a VMS or NVR.
Does it tell people apart from other motion?
AcuSense analytics classify human and vehicle targets specifically, which cuts down false alarms from irrelevant movement.
How is it powered?
It accepts PoE (IEEE 802.3af) or 12V DC, so it can run off a PoE switch/NVR port or a standard 12V supply.
