Product Description
What it does: the Hikvision iDS-7204HUHI-M1/XT is a 4-channel, 1U recorder that takes both analogue and IP cameras, so it suits anyone upgrading an existing coax-cabled site without ripping out the wiring.
Why the hybrid input matters
It accepts five signal types — HDTVI, AHD, CVI, CVBS and IP — on the same box. That means you can keep 4 existing analogue cameras running and add IP cameras (up to 8 channels, each up to 8MP) as the system grows.
Analytics worth knowing about
AcuSense is Hikvision's deep-learning filter: it tells people and vehicles apart from moving branches, shadows or animals, cutting false alerts. Two channels can run facial recognition; up to four channels support perimeter protection.
Recording and storage
- Records up to 8MP at 8fps on one channel, or 5MP at 12fps
- Uses H.265 Pro+ compression to keep file sizes manageable
- Takes one SATA hard drive up to 12TB — buy this separately, as the unit ships without one on some listings
- HDMI and VGA outputs run simultaneously up to 2560×1440
Other connections
RS-485 for PTZ camera control, Ethernet for remote viewing, USB for backup, and two-way audio over coax or RCA when paired with compatible cameras.
Good fit for a shop, small office or home installation that wants smarter alerts layered onto four cameras now, with room to add IP cameras later.
Specifications
- Model
- iDS-7204HUHI-M1/XT
- Series
- M-Series
- Channels
- 4-CH
- IP Channels (Hybrid)
- Up to 8
- Video Compression
- H.265 Pro+, H.265 Pro, H.265, H.264+, H.264
- Recording Resolution
- 8MP@8fps, 5MP@12fps, 4MP@15fps, 1080p, 720p
- Frame Rate
- 8 fps @ 8MP / 12 fps @ 5MP / 15 fps @ 4MP
- Decoding Capability
- 4 Channels
- HDMI/VGA Independent
- Sync
- Max Output Resolution
- 3K (2560 × 1440)
- BNC Output
- Yes
- Max HDD per Bay
- 12TB
- Max Total Storage
- 12 TB
- eSATA Port
- No
- AcuSense
- Yes
- DeepinMind / AI
- No
- Human & Vehicle Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- Yes
- Perimeter Protection
- Yes
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- False Alarm Filtering
- Yes
- People Counting
- No
- Audio Input
- 1 RCA + 4 via coax
Technical Specifications
Frequently Asked Questions
Can this DVR use my existing analogue cameras and add IP ones later?
Yes — it accepts HDTVI, AHD, CVI and CVBS on its 4 analogue channels, and can expand to 8 IP camera channels at up to 8MP each.
Does it come with a hard drive?
It supports one SATA HDD up to 12TB, but check your specific listing as some variants ship without a drive fitted.
What does AcuSense actually improve?
It's Hikvision's deep-learning filter that distinguishes people and vehicles from other movement, such as shadows or animals, reducing false alarms.
How many cameras can use facial recognition or perimeter protection?
Facial recognition works on up to 2 channels, and perimeter protection is supported on up to 4 channels.
