Product Description
This is a 16-channel hybrid DVR that accepts a mix of camera types, so it suits sites where you're upgrading gradually rather than replacing every camera at once.
What "hybrid" means here
It records from HDCVI, AHD, TVI, CVBS (analogue) and IP cameras on the same unit. That means you can keep existing analogue cameras running while adding IP cameras later, instead of ripping out a working system.
Key specs
- 16 channels total, with up to 12 IP camera inputs, each up to 5MP resolution
- Max 64 Mbps incoming bandwidth for IP streams
- H.265+/H.265 dual-stream compression — a newer encoding standard that reduces file size versus older H.264 systems, so footage takes up less storage for the same quality
- Full-channel AI-Coding support
- Up to 8 analogue channels with SMD Plus (a smarter motion-detection method that flags moving objects rather than every pixel change, cutting down false alerts)
- HDMI and VGA outputs for connecting a monitor
Before you buy
Check how many of your cameras are IP versus analogue, since the 12-channel IP limit and 8-channel analogue SMD Plus figure both cap what the recorder can handle at once. Also confirm your hard drive plans — this DVR supports internal and external storage, but the drive itself is a separate purchase.
Specifications
- Brand
- Unbranded
- Channels
- 16
- Colour
- Black
- Max Resolution
- 5 MP
- Storage Capacity
- Up to 10 TB
- Technology
- XVR
- Video Compression
- H.265/H.265+
- Video Inputs
- TVI/AHD/CVI/CVBS/IP
- Video Outputs
- HDMI, VGA
Frequently Asked Questions
Can I mix analogue and IP cameras on this DVR?
Yes — it's a hybrid recorder supporting HDCVI, AHD, TVI, CVBS and IP cameras, with up to 12 of the 16 channels usable for IP cameras.
What's the maximum camera resolution it supports?
Each IP channel supports up to 5MP, matching the DVR's 5MP rating.
Does it come with a hard drive?
The source material doesn't specify an included drive; it confirms support for internal and external storage, so check separately before buying.
What does SMD Plus do?
It's a smarter motion-detection method available on up to 8 analogue channels, designed to flag genuine moving objects rather than every pixel change.
