Product Description
What it does
The ANNKE D941BB is a 4-channel recorder that lets you run up to 8MP (4K) analogue cameras, IP cameras, or a mix of both on one box — handy if you're upgrading an older system without ripping out every camera.
It's a "5-in-1" DVR, meaning it reads four different analogue signal types — TVI, AHD, CVI and CVBS — plus IP input, so it should recognise most existing analogue cameras you already have wired in, in addition to newer IP ones.
Key specs
- Max resolution: 8MP / 4K (3840 × 2160) on supported analogue cameras
- Channels: 4 analogue BNC inputs, hybrid/IP capable
- Compression: H.265+, H.265, H.264+/H.264 — newer compression keeps file sizes down, so you get more recording time on the same hard drive
- Outputs: HDMI and VGA for a monitor or TV
- Detection: Human & vehicle detection on analogue channels — filters out false alerts from pets, shadows or moving branches
- Remote access: ANNKE Vision app, web browser or mobile
- Storage: One SATA slot, supports 1TB and larger drives
- Power: 12V DC
Before you buy
Check your existing cameras are TVI, AHD, CVI or CVBS (analogue) or IP — this DVR won't take other proprietary formats. You'll also need to buy a compatible SATA hard drive separately, sized to how long you want footage kept.
Specifications
- Brand
- ANNKE
- Resolution
- 8MP
Technical Specifications
Frequently Asked Questions
Will this DVR work with my existing analogue cameras?
If your cameras are TVI, AHD, CVI or CVBS format, yes — the D941BB reads all four signal types plus IP cameras on the same recorder.
Do I need to buy a hard drive separately?
Yes, the D941BB has one SATA interface and supports drives from 1TB upwards, but the drive itself isn't included.
Does it reduce false motion alerts from pets or trees?
It includes human & vehicle detection on the analogue channels, which is designed to cut down false triggers from pets, shadows or foliage.
Can I view footage remotely on my phone?
Yes, remote access is available through the ANNKE Vision app, a web browser, or another mobile device.
