Product Description
A wireless magnetic contact does one job well: it tells your alarm panel the moment a door or window leaf opens. The DS-PDMC-EG2-WE(B) is the AX PRO Series version, built for wireless zone coverage rather than a cabled setup.
What it does
A reed switch sits in the main unit, fixed to the frame; a small magnet sits on the moving leaf. Separate them — door opens — and the panel gets the signal, with no cable run needed between the two parts.
What to check before buying
- Panel compatibility: this contact is part of the AX PRO intruder detection range, so it's intended for use with AX PRO panels — confirm your panel is from that range before ordering.
- Configuration: setup is done through an app, so naming the zone, checking sensitivity and testing the link can all happen without opening the panel enclosure.
- Battery: rated for 5 years, and the battery is replaceable, so the whole unit doesn't get thrown away once it runs flat.
- Warranty: covered for 2 years.
Where it fits
Because there's no cable to the leaf, it suits doors and windows that flex, retrofits where chasing in cable isn't practical, or any opening where running a wire would mean extra disruption.
Specifications
- Detection Method
- Opening Contact
- Detection Gap
- 43 mm Max
- Digital Processing
- Support
- Tamper Protection
- Front,Rear
- Alarm Input
- Normally Closed,Normally Open,Impulse Count
- Power Switch
- Power up enrolling
- Transmission Technology
- Tri-X Wireless
- Transmission Method
- Two-Way RF Wireless
- Transmission Frequency
- 868MHz
- Transmission Security
- AES-128 Encryption
- Transmission Range(Free Space)
- 1.6Km
- Frequency Hopping
- Support
- Enrolling Method
- Power up,Remote ID,QR Code
- Standard Battery Life
- Up to 5 years (standby time)
- Power Supply
- Battery powered
- Battery Type
- CR123A x 1
- Typical Voltage
- 3V
- Operation Temperature
- -10°C to 55°C (14°F to 131°F)
- Storage Temperature
- -20°C to 60°C (-4°F to 140°F)
- Operation Humidity
- 10% to 90%
- Weight
- 59 g
- Application Scenario
- Indoor
- DS-PWA96-Kit2-WE
- DS-PDB-MC-Brown
Technical Specifications
Frequently Asked Questions
Will this work with any alarm panel?
It's designed for the AX PRO intruder detection range, so it's intended to pair with AX PRO panels rather than other brands.
Do I need to rewire the door when the battery runs out?
No — the battery is replaceable, rated for around 5 years, so you swap the battery rather than replace the whole contact.
Can I set it up without opening the panel?
Yes, configuration such as zone naming and sensitivity is done through an app.
